$19.00

TSOP56 Opentop Programming Socket 0.5 IC Test Socket Flash Burn

Reviews

Product Feature :

1. Use double contact technology , contact more stable ,

2. The socket shell use special engineering plastic , high strength , long mechanical life ,

3. The shapnel use import beryllium copper , small impedance , good flexibility ,

4. Coating with ticken gold plating layer , contact ticken electroplate , lowest contact resistance , high reliability .



Product performance :

1. Material :

a)  Insulator , PEI , PPS

b) Shrapnel , beryllium copper  Be Cu Gold plating(30μ)    Over Nickel plating(50μ)



2. Electrical Specification :

a) Insulation resistance :  1000mΩ Min,At DC 500V

b) Voltage resistance : voltage resistance

c) Contact resistance :   exceed 25mΩ

d) PIN feet stretch : 55g/PIN(Normal)

e) Mechanical life : 100000Times

f) Operating temperature : Minus 65 degree to 55 degress

g) Operating force : exceed 0.9kg Max



3. Specification :

a) Type : TSOP 56-0.5

b) Pin pitch  : 0.5 mm

c) Pin Count : 56

d) Chip Dimension : 14*18 mm
